Sugatsune

HES3D-V135

Hinge Details
Overall Dimensions

160mm L x 35mm W x 40mm D

Style

Concealed

Screw Size

5mm

Cut Info
Recommended Cutters

8mm / 1/4"

Mortise Depth

20mm

Material Thickness

30mm

Files
Cut Files
Manufacturer Resources

HES3D-V135 - Installation.pdf

HES3D-V135.pdf


Made by Shaper Tools
