Simonswerk - TE 340 3D Concealed Hinge Concealed - 160mm L x 28mm W x 68mm D

Simonswerk

TE 340 3D Concealed Hinge

Hinge Details

Overall Dimensions

160mm L x 28mm W x 68mm D

Style

Concealed

Screw Size

M5 x 40mm

Cut Info

Recommended Cutters

8mm / 1/4"

Mortise Depth

33.5mm

Material Thickness

36mm

Additional Info

See manufacturer's instructions for frame offset
