Blum

Cruciform Mounting Plate

Mounting Plate Details
Style

Cruciform

Screw Size

5mm, #6

Required Additional Hardware

CLIP Top Concealed Hinge

Cut Info
Recommended Cutters

8mm, 3mm / 1/4", 1/8" / Engrave

Mortise Depth

11.5mm

Files
Report File Issues
Cut Files
Manufacturer Resources
  • Blum CLIP Series Attachment and Adjustment.pdf
  • Blum CLIP Series Detailed Information.pdf
  • Blum CLIP Series Hinge Identification Guide.pdf
  • Blum CLIP Series Installation Instructions.pdf
