Brusso - L-93 Offset Pivot Hinge Offset Pivot - 2.500" L x 1.245" W x 0.600" D

Brusso

L-93 Offset Pivot Hinge

Hinge Details

Overall Dimensions

2.500" L x 1.245" W x 0.600" D

Style

Offset Pivot

Screw Size

#8

Cut Info

Recommended Cutters

8mm / 1/4"

Mortise Depth

0.25"

Additional Info

Chisel sharp corners

Files

Report File Issues

Cut Files

Manufacturer Resources

Brusso_Hardware_LLC_Installation_Instructions_L-93_Pivot_Hinge.pdf
Brusso_Hardware_LLC_Tear_Sheet_L-93_Pivot_Hinge.pdf
