Tabouret Stool

By AndrewWR
|
BY-NC-SA 4.0 License
|
Updated Wed Aug 21 2024

A copy of a stool found in an Egyptian tomb, C3400 years old. Timeless design. This is the project that I invented ZedSled for. Unless you know another way to make 18"x14" pocket cuts, you'll need ZedSled for this.

> 2 hr
Advanced

19

Furniture

Files Included (18)

  • tabouret jig 1 22 degree.svg

    2 kB
  • tabouret jig 2 27.6 degree.svg

    2 kB
  • tabouret jig 3 workholding.svg

    2 kB
  • tabouret leg low mortices (two sides).svg

    2 kB
  • tabouret leg tenon.svg

    2 kB
  • tabouret seat top 0-88.svg

    17 kB
  • tabouret seat top 154-204.svg

    14 kB
  • tabouret seat top 206-278.svg

    20 kB
  • tabouret seat top 90-152.svg

    13 kB
  • Tabouret seat top pocket cuts.svg

    6 kB
  • tabouret seat top.svg

    52 kB
  • tabouret seat underside.svg

    56 kB
  • tabouret stretcher tenon.svg

    2 kB
  • tabouret top side underside drilling.svg

    2 kB
  • tabouret top leg mortices.svg

    4 kB
  • Tabouret top mortices.svg

    5 kB
  • tabouret top strtetcher underside drilling.svg

    3 kB
  • Tabouret top tenons.svg

    3 kB

Materials

about 3.6M or 57mmx57mm PAR ash

about 3.6M of 30mmx30mm PAR ash

14 x 300mm x 15mm ask dowel

Tools

Shaper Origin

Zedsled

8mm round nosed router bit

clearing bit

6mm o-flute bit for mortices

Instructions

This is another ZedSled project. In fact, its the project I invented ZedSled for. The design I was copyiing is at least 3400 years old (see the last photo) but I think it still looks contemporary. I don't think these instructions are complete, because so much of this project was experimental. I'm posting it on the hub imore as a demonstration of ZedSled but if someone does want to try this, get in touch and I'll try to fill in the gaps in the instructions for you. Dimensions: 442mm x 342mm x 350mm seat thickness 30mm legs 30mm x 30mm square section stretcher 30mm x 24mm section dowels 16mm stock for top 57mm x 57mm PAR ash Cutting list: top stiles: 57mm x 57mm x 442mm x 2 top rails: 57mm x 57mm x 276mm x 7 legs: 30mm x 30mm x 335mm x 4 long stretchers: 30mm x 24mm x 422 x 2 short stretchers : 30mm x 24mm x322 x 2 Cutting order: tabouret top mortices.svg (25mm deep) tabouret top tenons.svg (4 different heights, all 24mm deep) NB Cut tenons from highest to lowest and back up to highest, giving 2 pieces at each height except the lowest one. Seven pieces total tabouret seat underside.svg NB Cut diminishing radii as outside cuts with 8mm round nose bit. tabouret seat top.svg NB Cuts are inside so start at the middle. I recommend pocketing out the bulk of the wood first tabouret leg mortices.svg NB Machine 17mm off top of each leg post first then cut mortices 25mm deep. This was not done when cutting the underside curves because the longer leg posts provided orthogonal support when cutting the top. Dowel spindles : Short side spindles Vertical spindle:- Height of rail (B) = 100mm Cut depth for underside at centre of edge and 15mm in from edge (D) = 14.55mm Height of underside centre @15mm in from edge. (T) = 340-57-B+D = 197mm Hole depth (HD) 15mm Vertical spindle = T+HD+HD = 227mm Angled spindle:- Base drill centre= 126mm from centre of rail. Top drill centre= 22.5mm from centre of rail Cut depth for underside at top drill centre and 15mm in from edge (D) =14.84mm xdim = 103.5mm ydim = 340-57-B+D = 197.84mm Angled spindle = sqrt( xdim^2 + ydim^2) +HD+HD = 253mm Angle=27.6 degrees Pre-cut centre for top drill centre = top drill centre + Dsin(Angle)=29.4mm Drilling underside top: Vertical hole at 114 , 15 @29.55mm deep 27.6 degree hole (tending to centre) at 84.6,15 @33.7mm deep 27.6 degree hole (tending to centre) at 143.4,15 @33.7mm deep Drilling short stretcher Vertical hole at 141,12 @15mm deep (dimensions exclude end tenons) 27.6 degree hole (tending to end) at 15,12 @15mm deep 27.6 degree hole (tending to end) at 267,12 @15mm deep Long side spindles Vertical spindle:- Height of rail (B) = 70mm Cut depth for underside at centre+/-50mm of edge and 15mm in from edge (D) =9.2mm Height of underside centre @15mm in from edge. (T) = 340-57-B+D = 222.2mm Hole depth (HD) 15mm Vertical spindle = T+HD+HD = 252mm Angled spindle:- Base drill centre= 126mm from vertical spindle centres. Top drill centre= 22.5mm from vertical spindle centres Cut depth for underside at top drill centre and 15mm in from edge (D) =10.4mm xdim = 103.5mm ydim = 340-57-B+D = 223.4mm Angled spindle = sqrt( xdim^2 + ydim^2) +HD+HD = 276mm Angle=22 degrees Pre-cut centre for top drill centre = top drill centre + Dsin(Angle)=26.4mm Drilling underside top: Vertical hole at 171 , 15 @24.2mm deep Vertical hole at 271 , 15 @24.2mm deep 22 degree hole (tending to centre) at 144.6,15 @27.4mm deep 22 degree hole (tending to centre) at 297.4,15 @27.4mm deep Drilling long stretcher Vertical hole at 141,12 @15mm deep (dimensions exclude end tenons) vertical hole at 241,12 @15mm deep 22 degree hole (tending to end) at 15,12 @15mm deep 22 degree hole (tending to end) at 367,12 @15mm deep
