Drill rack cleat - Updated

Instructions

For a run through on how to cut this tool holder, watch the linked YT video! * If the SVGs included above are not right for your setup or if you would like to support my work then you can pick up fully parametric CNC files for this tool holder on my Etsy store: https://goto.hswdesign.co/drill-rack-cad All my cut files and plans are free for those who join me over on Patreon 👉 https://goto.hswdesign.co/patreon Parameters used in the drill rack SVGs are: --- METRIC for 60mm and 80mm Cleat Thickness of ply used for wall cleat - 17.8mm Thickness of ply used for bracket - 14.8mm Height of cleat face - 60mm Diameter of locking peg - 16mm Offset for locking peg - 0.1mm End-mill/bit diameter - 6mm End-mill/bit offset - 1mm Drill rack projection - 210mm Insert width - 82mm Insert width offset - 18mm Insert throat length - 90mm --- IMPERIAL for 3" and 2.5" cleats Thickness of ply used for wall cleat - 3/4” Thickness of ply used for bracket - 1/2” Height of cleat face - 3” Diameter of locking peg - 1/2” Offset for locking peg - 0.005” End-mill/bit diameter - 1/4” End-mill/bit offset - 0.02” Drill rack projection - 8.5" Insert width - 3.25" Insert width offset - 0.75" Insert throat length - 3.5"
