Workstation X zero point jig
You're putting a new workpiece on your workstation. Your Y has been fixed, but how about the X position? I've created this small jig to align your workpiece with the X zero point (given you have defined a grid).
10 min
Easy
62
Jigs & Fixtures
Files Included (2)
workstation-x-alignment-alt.svg
1 kBworkstation-x-alignment.svg
1 kB
Materials
A small piece of plywood, 20mm x 180mm
I used 6mm thickness, can be anything as long as it is sturdy enough.
Tools
Shaper Origin
Instructions
Use the "alt" if you want the jig to stick out from the top using the 25mm spacer, or the normal version if you want it to stay just below the surface. (Image is from alt version)
