Plane rack for french cleat
Storage rack for my planes, without any use of glue, nails or screws! Hang it on a french cleat system, with vertical distance of 30cm.
122
Cleats
Files Included (4)
schaafkast-inslag.svg
885 Bschaafkast-plank-boven.svg
1 kBschaafkast-plank-midden.svg
753 Bschaafkast-zijkant.svg
3 kB
Materials
12mm plywood
(optional) 3mm plywood for the back
Tools
Shaper Origin
Chisel / saw
Hammer
Sandpaper / router with rounding bit
Instructions
Optionally, cut a piece of 3 mm plywood to fit it in the back. 508mm x 482mm Route slots at 5mm depth and you'll have some room left to fit the back nicely. In some locations you need a saw or a chisel to make a sharp corner. The sides need to be rounded, either by hand (I used sandpaper), or you can route it with a router. When all the pieces are finished, you can hammer in the small wooden pieces into the holes.
