Dartboard Cabinet

By AmandaRussell
|
BY-NC-SA 4.0 License
|
Updated Thu Sep 19 2024

This cabinet involves techniques like the "rip and flip" method to create quartersawn material, The Krenov dowel jig method, kerf bending, and fitting curved doors. You will use the Origin to make a kerf bending form, custom mill brass, and create curved rails for door and back panels. You will also make matching solid wood door panels and a cork back panel with shadow grooves. The Workstation will allow you to cut mortises for offset knife hinges in the top of the curved door.

> 2 hr
Advanced

27

Cabinetry

Files Included (12)

  • Bending Form.svg

    2 kB
  • Brusso—L-39 Offset Pivot Hinge.zip

    195 kB
  • Cord Management Female and Male Plug.svg

    6 kB
  • Cutlist.pdf

    47 kB
  • Dartboard Cabinet - Back Panel.svg

    4 kB
  • Dartboardcabinet.skp

    5 MB
  • Door Panel - Left.svg

    2 kB
  • Door Panel - Right.svg

    2 kB
  • Door Top & Back Panel Top Templates.svg

    3 kB
  • light-sensor-cover-back.svg

    2 kB
  • light-sensor-cover-top.svg

    3 kB
  • Top Curve Veneer Template.svg

    3 kB

Materials

Case:

-Hardwood

(2) T 7/8"X W 5 3/4"X L 37 1/8"

(1) T 7/8" X W 5 1/2" X L 24"

(1) T 5/8"X W 5 1/2" X L 26"

Doors:

-Hardwood

(2) T 1"X W 1 1/2" X L 34 13/16"

(2) T 7/8"X W 1 5/8" X L 33 1/8"

(2) T 3/4"X W 3 1/2" X L 12"

(2) 3/4 1 5/8 12

(2) T 1/2""X W 9 7/8"X L 32 5/8"

-Cork

(1) T 1/4"x W 24"x L 48"

Back Panel:

-MDF

(1) T 1/4" X W 21 1/2" X L 32 1/4"

-Hardwood

(1) T 3/4" X W 2 7/8" X L 23 1/2"

(1) T 3/4" X W 1 1/4" X L 12 15/16"

(1) T 3/4"X W 1 1/4" X L 11 13/16"

(1) T 3/4" X W 1 1/4" X L 32 5/8"

(1) T 3/4" X W 1 1/4" X L 28 1/4"

3/4 1 1/4 5 5/8

-Cork

(1) T 1/4"x W 24"x L 48"

Drawer:

Hardwood -

(2) T 5/8" X W 4 3/8" X L 4 3/8"

(2) T 5/8" X W 4 3/8" X L 10 1/8"

(1) T 1/4" X W 4"X L 8 7/8"

Bending Form:

MDF:

(1) T 3/4"X W 24"x L 25"

(1) T 1/8"x W 5.5" x L 25"

Brass Hardware:

(2) 1.5"x1.5"x.125" Extruded brass angle. 4" long.

-Hardwood

(2) T 1/8" x W 1.5"x L 2"

Cord Cover:

-Hardwood

(1) T 1/8" X W 2" X L 4 1/2"

Light Sensor:

-Hardwood

(1) T 5/8" X W 1 5/8" X L 2 3/4"

Tools

Shaper Origin

Shaper Workstation

⅛” X ¼” Up-Spiral O-flute Router Bit

¼” X 1” Up-Spiral Flat Router Bit

1/4" Collet

Miter Saw

Jointer

Planer

Tablesaw

Router Table or Router

Bandsaw

Vaccum Bag

Clamps

Instructions

Check out Shaper Sessions and my YouTube video series for instructions.
