Lamello Zeta P-system
Template for making holes to align with Lamello Zeta positioning pins and clip calibrated for 18mm ply.
10 min
Easy
16
Hardware Inserts
Files Included (2)
zeta_board_lamello.svg
51 kBzeta_edge_lamello.svg
49 kB
Materials
18mm plywood
Tools
Shaper origin
3mm upcut bit
Lamello Zeta P2
Lamello positioning pins 251048
Lamello positioning clip 251067
Instructions
Template for making holes to align with Lamello Zeta positioning pins and clip. Custom anchor points at center, offset of 9.5mm on edge for 18mm ply. Zeta_edge file is for 6mm positioning clip, Stay visible and used for the Clamex hex wrench. Zeta_Board is for zeta routing into the face of the board (hole not visible afterwards) Can be useful in a hybrid approach with tracksaw and zeta for joining.
