ZSWS : ZedSled for Workstation.

By Erik_WW
|
BY-NC-SA 4.0 License
|
Updated Mon Oct 14 2024

With this jig you can increase your (supported) work area from 420x120mm to 380x320mm Inspired by the ZedSled of AndrewWR I made a version that could be mounted on the supports of the Workstation. Maximum cut depth is reduced by 3 mm.

> 2 hr
Intermediate

33

Jigs & Fixtures

Files Included (1)

  • Zedsled WS 380 w15 V2.svg

    17 kB

Materials

See https://community.shapertools.com/t/zsws-zedsled-for-workstation/13719

Tools

See https://community.shapertools.com/t/zsws-zedsled-for-workstation/13719

Instructions

This project was inspired by @AndrewWR : https://hub.shapertools.com/v2/creators/63b611f2fbe48653c207db8d/shares/6632aa366036cdb4caa5a7c6 There is a subject in the Forum with the full instructions and room for remarks and discussion. https://community.shapertools.com/t/zsws-zedsled-for-workstation/13719 Update to V2 (see forum subject - follow link above) Changes: -Bottom 2040 now 600 mm long for smoother action -Wheel holders adapted to allow some adjustment for smoother movement
