Rubber Band Gun: Lever-action Winchester Rifle

By mberg|BY-NC-SA 4.0 License|Updated April 12th, 2021

uploaded project imageuploaded project image
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
This project includes the parts needed to build the level-action Winchester Rifle from the RBGuns site. RBGuns has created incredible designs for different rubber band guns with fully functional mechanical trigger actions made out of wood. In this project, I just worked to convert the plans to something you can build with your Shaper. https://www.rbguns.com/english/lever-action-rifle/

2 hr

Intermediate

62

Files included (49)
NameSize
Rubber Band Gun/Parts 1-10/part-1.svg
3 kB
Rubber Band Gun/Parts 1-10/part-10.svg
1 kB

-4mm plywood ca. 1400x600mm -ø16mm hardwood dowel 1x446mm 1x285mm -ø6mm hardwood dowel ca. 60mm -ø4mm hardwood dowel ca. 150mm -9x screw 3x20mm -rubber bands ø40mm, ø100mm
- Shaper - Glue
Please go to the RB Guns site to download the instructions and part list. RBGuns has also put together a detailed video on how to build this rubber band gun along with a fun video of the RB gun in action. https://www.rbguns.com/english/lever-action-rifle/ To build the gun cut out the parts and follow the instructions in the guide. Until you start assembly, it largely constitutes glueing parts together. I labeled each of the SVGs to match the part number in the instructions. A couple of caveats on the design. The designs are in metric. If you live in the US this has a few practical implications. The design calls for 4mm plywood which is 0.157 inches. I ended up using 1/4 ply which worked find but resulted in a thicker gun. If I was to build the gun again I may try and use 1/8 inch ply. For the 6mm dowels I used a 1/4" dowels. Since 1/4 inch is slightly bigger you will need to cut the 6mm holes with a slight negative offset until the 1/4 dowel fits. I forgot what this is so you'll need experiment to figure that out. The design is a marvel of engineering and if you follow the instructions closely you'll end up with a rubber band gun that works great and holds up surprisingly well. Please note in the image I shared, I actually didn't finish the gun (I didn't add the lower barrel). This is largely due to the impatience of my son wanting to play with this. Again all credit for this project is due to RB Guns along. They also retain full ownership of these designs. I'd encourage you to checkout their site has they've developed a number of incredible designs. If you like the work, please consider supporting RB Guns by buying something on Amazon through their affiliate site: https://www.rbguns.com/shop-1/
