Hatchet / Throwing Ax

By mberg | Created July 31st, 2020 | Published July 31st, 2020 | Updated July 31st, 2020

uploaded project imageuploaded project image
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
Wooden hatchet / throwing ax I made for my son. First time using Fusion 360 so was fun to figure out how to draw this. About 14.5" long and 1.5 wide" in the handle. Would probably shrink dimensions to 12" next time. Throws nice

30 min

Easy

2

Category

Toys

Files included (1)
NameSize
hatchet.svg
14 kB

3/4" ply
SO 1/4 bit Hand router Sand paper
Use 3/4" ply. 1/2 ply would also work well if you are ok with a thinner handle. Do 3 outside cuts with a 1/4 bit at 0.25/0.5/0.7" with a 0.03 offset then a cleaning cut at at .76" with 0 offset. Round edges with a hand router and sand Give to kid with instructions not to wack anyone.
