Stool

By IFlorianI | Created August 17th, 2020 | Published August 17th, 2020 | Updated August 17th, 2020

uploaded project imageuploaded project image
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
My thought on this project was to design and make a useful piece of furniture that, apart from solid wood planing, can be made using only the Origin. Still a prototype with some needs of optimization and still a pleasure to be able to sit down after work :D

1 hr 30 min

Easy

16

Category

Furniture

Files included (6)
NameSize
stool seat.svg
9 kB
upper bar.svg
6 kB

black MDF (any other available color is of course conceivable) ca. 1130 × 400mm european fir (any other sufficiently stable wood is of coures conceivable) 6× boards with finished dimensions: ca. 450 × 70mm ordinary wood glue oil based surface coat or a surface-treatment of your choice (some waste material for your templates)
basic Handtools + clamps ca. 500mm Shaper Origin + standard router bits: 3mm spiral upcut router bit + 45° engraving bit (for the grooves in the seat plate) 6mm spiral upcut router bit (corner joint) 8mm spiral upcut router bit (rabbet and outer contour) (a hand-held circular saw with rail or a table saw as an alternative could help at some point) (basic Tools for sanding and to apply an oil based surface finish)
here´s a links for the surface finish I used: https://www.holz-kunz.de/osmo-hartwachs-oel-original?number=100010.9&sPartner=gshopping&gclid=CjwKCAjw1ej5BRBhEiwAfHyh1CuJuL9dE9Fqk2_-JBemNG7uwuTekiZkOywQf1MeY4uc684V5ft4JBoCYLwQAvD_BwE and another link for the MDF: https://www.forescolor.de/home.html I have attached a pdf to my files with a detailed description and photos of the manufacturing process. please let me know if you have any problems with the files here are links to my instagram accounts with more projects I did in the past: @_sepparee_ @polyholz @_flomeigel_ I look forward to any kind of feedback. Have fun!
