Alm Fab OFF/SET Nesting Trays
Set of 3 nesting trays designed by Michael Alm. Outside dimensions 20" x 13" x 4.25" (508mm x 330mm x 108mm)
560
Decor
Files Included (7)
alm_fab_nesting_trays_v1.pdf
126 kBinner_long_v02.svg
938 Binner_short_v02.svg
905 Bmiddle_long_v02.svg
629 Bmiddle_v02.svg
1 kBouter_long_v02.svg
904 Boutter_short_v02.svg
901 B
Materials
Side panels: 0.5" (13mm) material
Outer 66" @ 4.25" (1675mm @ 108mm)
Middle 62" @ 3.75" (1575mm @ 95mm)
Inner 58" @ 3.25" (1475 @ 83mm)
Bottom Panels (Recommended that you cut panels to fit) : 0.5" (12mm) material
Outer approx. 19.6875" x 12.6875" (500mm x 322mm)
Middle approx. 18.5625" x 11.5625" (471mm x 293mm)
Inner approx. 17.4375 x 10.4375" (443mm x 265mm)
Tools
Can be built entirely with Origin and Workstation, but a table saw will speed up the process.
I've also included templated so this project can be built with traditional woodworking tools.
Instructions
Cut list for side panels: Outer Long sides 20" x 4.25" x 0.5" (508mm x 108mm x 13mm) Short sides 13" x 4.25" x 0.5" (330mm x 108mm x 13mm) Middle Long sides 18.9375" x 3.75" x 0.5" (481mm x 95mm x 13mm) Short sides 11.9375" x 3.75" x 0.5" (303mm x 95mm x 13mm) Inner Long sides 17.875" x 3.25" x 0.5" (454mm x 83mm x 13mm) Short sides 10.875" x 3.25" x 0.5" (276mm x 83mm x 13mm) Cut list for bottom panels: (Recommended that you cut panels to fit) These can be made from 0.25" (6mm) material or 0.5" (12mm) material with a 0.25" (6mm) rabbet Outer approx. 19.6875" x 12.6875" (500mm x 322mm) Middle approx. 18.5625" x 11.5625" (471mm x 293mm) Inner approx. 17.4375 x 10.4375" (443mm x 265mm)
