MCM magazine rack
A mid-century modern inspired magazine rack with two compartments. Visible thru-tenon joinery and leather interlock hardware. Small top shelf to rest a magazine or book. Carrying handle for easy relocation. Tapered sides match natural angle of the hanging fabric. Fabric is easily removable for cleaning or style updates.
43
Furniture
Files Included (3)
end tenon 1.svg
356 Bend tenon 2.svg
356 BMCM rack copy.svg
52 kB
Materials
(1x) 8" x 7' hardwood board, 3/4" thick
(1x) leather hide, 1mm thick, 17" x 60", laser cut
(6x) brass pins, 1/4" diameter, 75 mm long, rounded ends, polished [McMASTER 8953K124]
(6x) #8-32 threaded inserts, brass, 3/8" long, hardwood [McMASTER 90016A009]
(6x) #8-32 washers, brass, 0.437" OD [McMASTER 92916A340]
(6x) #8-32 machine screws, button head, slot drive, 7/8" long, brass [McMASTER 92453A198]
(1x) spool of wax thread for leather stitching
Tools
Shaper Origin
Shaper edge joinery jig
Festool Domino
Leather stitching tools
Laser cutter for leather (or order online)
Wipe-on polyurethane varnish
Instructions
Wood - All wooden part profiles and most features cut from the 8" wide hardwood board - end frames assembled with 6mm x 19mm loose tenon at each corner (see wireframe image) - edge rounds completed using handheld trim router on loose parts - all wood parts sanded to 320 grit and finished with wipe-on polyurethane Brass Hardware - dowel pins cut down from brass rod, ends ground, polished on buffing wheel - threaded inserts underneath top shelf allow removal and re-install of fabric without damaging wood Leather - laser cut, including stitching holes - loops at each end are sewn, fed through the wood slots, and then the pin is inserted to lock - leather is clamped between top shelf and a lower clamping board using brass screws
