Inverted Jigsaw table Workstation add-on
Plate for mounting a Festool PS300 Jigsaw upside down. It is using the workstation support arms and 3d printed parts to secure the plate to the arms and the Jigsaw to the plate. See https://www.printables.com/model/530404-shaper-workstation-inverted-jigsaw-table for the parts and additional instructions.
12
Shaper Workstation
Files Included (5)
bandsaw v40.f3z
3 MBbandsaw_bottom.svg
6 kBbandsaw_simple.svg
23 kBbandsaw_top_hole_simple.svg
13 kBbandsaw_top_hole.svg
7 kB
Materials
3/4'' melanine covered plywood
2* M8 Bolt and Nut
6 Flat wood screws #8 3/4'' long
6 Flat wood screws #8 1/2'' long
7 10-24 Flat Head Screws 3/4'' long and nuts
3d printed parts from https://www.printables.com/model/530404-shaper-workstation-inverted-jigsaw-table
Tools
Shaper Origin
Track saw for straight lines (optional)
3d printer
1/4'' and 1/8'' bits
Countersink bit
Instructions
Print the 3d parts first. The dimension are for a tight fit. A .1 to .3 mm offset needs to be added, depending on the part printing. .1mm was added to the sides, .2 to the front and .3 to the back. 2* 40mm knobs and rests are the same as the one used in https://hub.shapertools.com/creators/5bcf493945760d0017441fce/shares/64ab909667eb5a559513d52e The thickness of the plate in fustion360 file is parametric. The side adapter could be used for attaching other plates flush with the workstation core.
