MFT3 Cart

By gwendal | Created January 10th, 2021 | Published January 10th, 2021 | Updated January 10th, 2021

uploaded project imageuploaded project image
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
Inspired by other MFT3 carts, allow storing systainers, using VAC SYS at lower height and move easily around.

2 hr

Easy

11

Category

Storage & Organization

Files included (7)
NameSize
frame.svg
15 kB
side34.svg
23 kB

BY-NC-SA 4.0 License


4x8 + 4x4 3/4 plywood (sides + shelves and other) ~ 4x4 1/2 plywood (middle and recess) 4x4 Melamine covered plywood (top) 3/4'' x 12'' x 8' pine board (use something else, too soft). 4 5'' Casters: https://www.mcmaster.com/2502T43 4 28'' drawer slide pairs: https://www.mcmaster.com/11435A41 6 corner braces: https://www.amazon.com/gp/product/B0714FP9LB/ref=ppx_yo_dt_b_search_asin_image?ie=UTF8&psc=1 16 1/4'' x 1 1/4'' screws (for casters), nuts 40 5mm x 11.5 mm "Euroscrews" (for shelves): https://www.woodcraft.com/products/5mm-x-11-5mm-highpoint-euro-screws-flat-head-pozidrive-100-pc?sku=154122
Shaper Origin Track Saw/Rail Edge Trimmer
Inspired by MFT3 cart project on festool - https://festoolownersgroup.com/index.php?pretty;board=festool-jigs-tool-enhancements;topic=mobile-mft3-build.msg331957#msg331957 https://www.festoolownersgroup.com/festool-jigs-tool-enhancements/expandable-(triple-wide)-mobile-compact-mft3-cart/ Cart is built with left over wood from other projects. The parameters in .f3d (caster height, wood thickness) ensure the produced cart height is at 900mm. The top is slightly smaller than the MFT3 to ensure snug fit (and avoid an extra pass with the shaper). The top has holes for the Shaper Workstation and Dewalt 735 planer. Smooth melamine allows securing the VAC SYS in vacuum mode. There are french cleat rails (https://community.shapertools.com/t/cleat-wall-strip-size-and-spacing/2882/4) in the back for extension and underside beams, both for strength.
