TriStool and Fixture, BenchPilot Ready
This fixture is meant for batch production of the leg tenons in our Tri Stool project. While you can use this fixture with Origin manually, it's even better with BenchPilot! Note this is designed with 1.25" thick hardwood in mind for the stool. Also included in this project are files for the leg profiles nested together; the tenon file optimized for BenchPilot; and a round stool top scaled to fit on the Shelf Upgrade Kit.
2
Jigs & Fixtures
Files Included (4)
stool legs nested 4 BP.svg
2 kBstool tenon gang fixture v2 .svg
9 kBTristool Circle Seat 4 BP.svg
6 kBTriStool Tenon 4 BP.svg
3 kB
Materials
- 3/4" plywood
- 1 1/4" hardwood (for cross clamp)
- McMaster Hardware (see link list)
-Adhesive backed rubber (firm)
Tools
-Origin
-8mm x 35mm bit
-5mm x 20mm o-flute bit
Instructions
Order hardware first so you can dial in fit. McMaster Hardware Links: - (6) Fixture Clamps https://www.mcmaster.com/84865A13/ - (6) 10-32 Threaded Inserts https://www.mcmaster.com/95807A430/ - (18) Locating and Support Buttons https://www.mcmaster.com/8506A16/ - (18) M5 x 18mm Socket Head Screws https://www.mcmaster.com/91290A238/ - (18) M5 Tee Nut Inserts https://www.mcmaster.com/98965A102/ - (2) Toggle Clamps https://www.mcmaster.com/5135a23/ Once you have finished cutting out the fixture, use a forstner bit to cut a shallow recess for the tee nuts to be hammered in flush from the back. When you are ready to cut your first batch of tenons, each leg must be probed for a grid and file placed individually.
