T Dovetail Joint
A shouldered dovetail to easily add strength and style to your project. https://www.youtube.com/watch?v=eOP1jNcDov0&feature=youtu.be
177
Joinery
Files Included (1)
T_Dovetail_test.svg
3 kB
Materials
-1” x 1” solid wood (adjust for your material dimensions as needed)
-wood glue
-sandpaper
Tools
-Shaper Origin
-1/8” endmill cutter with 1” length of cut
-milling tools (jointer, planer, etc.)
-Sander
Instructions
-There are many different cut paths close together in this project. Be sure to use the appropriate depth for each path. Negative Side: Divide depths appropriately to your material thickness (1” in this case). -1st path (dovetail shape) -1/2” deep -2nd path -3/4” deep -3rd path -1” depth Positive Side: -1st path (shoulder) -1/4” deep -2nd path (2nd shoulder) -1/2” deep -3rd path (dovetail) -1” deep
