Kapex Zero Clearance Insert

By WoodwerdTX | Created November 5th, 2018 | Published November 5th, 2018

uploaded project imageuploaded project image
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
Festool Kapex Zero Insert

10 min




Hardware Inserts

Files included (3)
KapexZero Insert v0.png
285 kB
4 kB

Ideally Oak or other Hardwood planed to 7.5mm - 7mm thickness
Shaper with 1/8" bit
I have tried to confirm tolerances but even the Kapex Supplimental manual has about a 1mm of tolerance to my Kapex. But most should be able to dial this in with the screws leading the way. I did the bore for sholder of screw to .15" depth about 5mm. OoO 1) Mill center holes 2) Mill counterbore holes 3) Mill outside profile I have added a SLOT version of the design. It is better at accomidating the largest tolernace it seems which is the width and is as closest to the intent of Festool engineering. If anyone wants the Fusion360 file to tweak dimensions for your own saw let me know.

This project is licensed under the Creative Commons Attribution - NonCommerical - Share - Alike license
