Spice Rack 7 shelf
A custom spice rack to accommodate multiple spice containers. Plenty of space added for different sizes. 7 shelves with plenty of overhead for tall containers.
21
Kitchen
Files Included (4)
leftSide.svg
6 kBlip01.svg
2 kBrightSide.svg
7 kBshelf01.svg
862 B
Materials
18mm (3/4") plywood
2x flush mount keyhole hanging brackets (width < 16mm likely)
Your favorite wood glue/adhesive
Tools
Shaper Origin
Mallet
Instructions
Cut out one left side and one right side piece. Then cut 7x shelves and 7x lips. Depth cuts (gray regions) are 9mm for all pieces. Designed in Fusion 360 with a very good free add-in from GitHub (https://bit.ly/2XCEc2x) for creating the dog-bones. I designed this to be a quick cut with no tool changes (1/4" bit only, hence the dog-bone sizes). Intent is to hang the unit via “flush mount keyhole hanging brackets” that are installed near the top on the backside of the main side pieces. An example of a keyhole cutout can be found here: https://hub.shapertools.com/creators/59d2a95f735c740010ba2968/shares/5b9b4595bc0fd4001796a0c6 . I’ll leave it to you to find your own hardware, and create your own flush mount template.
