Spoil Board Keeper
Keeps the spoil board in place when the support arms are not being used.
46
Jigs & Fixtures
Files Included (1)
Shaper WS Short Arm V5.svg
1 kB
Materials
3/4" PVC Trim Board (6"X6")
Double sided tape
5/16"X 18 Nylon Screws McMaster-Carr Part # 91970A587
Tools
5/16" X 18 Tap
¼" Amana Tool - 51404 Solid Carbide CNC Spiral 'O' Flute, Plastic Cutting 1/4 Dia x 3/4 x 1/4
Instructions
Cut two profiles with a slow enough spindle speed to prevent melting the PVC. Tap each hole completely through. Insert a plastic screw from each side. Tighten the top screw until it fits snug enough to stay in place in support arm mount. (it will snap into place with little effort) The bottom screw needs to protrude through until the Non-Threaded portion is past flush (to jam in place). Trim the outside screw ends flush.
