Long Cleat Clamp Rack

By Gary1 | Created January 19th, 2020 | Published January 19th, 2020 | Updated January 19th, 2020

uploaded project imageuploaded project image
project image thumbnailproject image thumbnail
project image thumbnailproject image thumbnail
This based on the Cleat Container Systainer Shelf project provided by Shaper. It will work with up to four K-type clamps.

30 min

Easy

11

Category

Cleats

Files included (3)
NameSize
Cleat Clamp Rack Long Left Side.svg
3 kB
Cleat Clamp Rack Long Middle.svg
1 kB

3/4" Baltic Birch Plywood Double Sided Tape ShaperTape Glue Sandpaper
1/4" spiral bit. A downcut for pocketing would be preferred, as well as a 1/4" compression bit for part cut out. 1/16" router bit. Not required if you want to use a chisel to cleanup the pocket in the left and right sides instead.
As stated in the description, this is based on the Cleat Systainer Shelf : https://www.shapertools.com/hub/creators/5b437481a92ce901517c0655/shares/59eecacaa92ce9014344b5cc Use the instructions shown in the link above if you want to create locking disks. Use a regular 1/4" bit or compression bit to cut out the parts first. Then use a quarter inch regular bit or downcut bit to clear the pockets. Change the pocket to an inside cut, and cut the inside. Doing it in this order with a downcut bit will prevent chipout. Cut the pockets on the left and right sides to a depth of 1/4". If you have a 1/16" bit, you can use it to cut the dogbones in the left and right side pockets, otherwise use a chisel to square up the corners at the back part of the pocket. The pockets are designed for plywood with a thickness of 0.73". Expand or reduce the pockets as needed to fit the thickness of your plywood. Note that the arms in the version I built were 3/4" too long. I've fixed the vectors in this uploaded version.

This project is licensed under the Creative Commons Attribution - NonCommerical - Share - Alike license
