Battery Dispenser

|
|
Updated Fri May 22 2020

I used this project to learn and practice using Fusion 360. The dispenser holds: 10 - D 13 - C 23 - AA 19 - 9V 32 - AAA All of the files are based off of a material thickness of 11.95mm (for a very tight fit, no glue required!).

Advanced

68

Storage & Organization

Files Included (8)

  • All_11.95mm.svg

    24 kB
  • Back_11.95mm.svg

    6 kB
  • Bottom_11-95mm.svg

    3 kB
  • Divider_11-95mm.svg

    1 kB
  • Front_6mm_plexi.svg

    3 kB
  • Left Side_11-95mm.svg

    1 kB
  • Right Side_11-95mm.svg

    1 kB
  • Top_11-95mm.svg

    3 kB

Materials

*450mm x 900mm 1/2" sheet of plywood

*7" x 12" of 6mm cast acrylic plexiglass

Tools

Shaper Origin (that's it!)

Instructions

I have a complete set of instructions and things I learned during the process on my blog... https://www.beezleecreations.com/blog/2020/5/19/fusion-360-battery-dispenser
