Kreg Automax adapter base for Workstation
By
BrianJ
|
BY-NC-SA 4.0 License
|
Updated January 12th, 2021
A simple adapter that turns the KREG Automax bench clamp into a sliding T-slot clamp that locks in place.
30 min
Easy
29
Jigs & Fixtures
Sync to My Files
Download All Files
Success! Check your Inbox
Files included (4)
Name
Size
KREG CLAMP FOOT bottom.svg
2 kB
KREG CLAMP FOOT dims.pdf
12 kB
show more
Materials
KREG Automax bench clamps T bolts GPO-3 plastic or other strong material, 3/8" to 1/2" (10mm to 12 mm) thick. About 4" x 2" per unit (100mm x 50mm) A knob, can be shop made. Nylon Washers
Tools
Shaper Origin 1/8" bit. 1/4" bit. Double sided tape.
Instructions
Place and cut the top first, and let the 1/8" cutter cut down into the spoilboard a little. Delete the file just cut, then place the bottom file using the same anchor point at the same grid point. Flip the workpiece and line the 1/8" hole up on the holes left in the spoilboard, then cut the bottom. Pockets are just deep enough to flush the hardware. If you have a tool with a large T-slot (example, sliding table saw) the adapter can be used. A file of the shop made knob in image 2 is here:
https://hub.shapertools.com/creators/59d26925735c740010ba2896/shares/5c2134252800470017e9416c
More images and discussion at:
https://community.shapertools.com/t/workstation-clamp-upgrade-with-gpo-3-industrial-structural-plastic/6421
