Teaching aid : Origin camera area

By Sam
|
BY-NC-SA 4.0 License
|
Updated Fri Jan 17 2025

Cut a quick education aid to visualize what the Origin camera is looking at to a class. both gen 1 and gen 2 visible areas to help people understand where Origin is looking for Shapertape.

10 min
Easy

32

Other

Files Included (2)

  • Gen1_Vis_v002.svg

    12 kB
  • Gen2_Vis_v002.svg

    7 kB

Materials

3mm acrylic ( anything thin and strong )

Tools

1/8" short oflute cutter

Instructions

I cut this to the full depth in one pass. perform a test cut to determine the settings that work for you. rpm = 4 depth = 3mm offest = 0
