SWS larger Shelf with index pins

By Sam
|
BY-NC-SA 4.0 License
|
Updated Tue Jun 09 2020

A larger shelf with configurable delrin index pins, designed to support larger projects or to enable several smaller pieces to be mounted at once.

10 min
Easy

100

Shaper Workstation

Files Included (1)

  • mid_shelf_pins_v004.svg

    60 kB

Materials

3/4" MDF

1/4" diameter, 3/4" long delrin pins

Tools

Origin

1/4" stock cutter

Instructions

Cut all interior details first. pins holes should be helix cut to 1/2" deep sholder on the mounting holes is designed to be cut to 1/2" deep then cut the perimeter. note: this is designed assuming double sided tape will be used to secure stock in place. also, the shelf position may move a small amount when loosened and repositioned, consistent indexing against delrin pins should only be expected if shelf is not repositioned.
