SWS shallow tslot shelf
This small shelf helps with producing a small batch of modest sized items, with customisable delrin indexing pins and a low profile clamp for fast repeatable fixturing.
120
Shaper Workstation
Files Included (1)
mini_shelf_pins_tslot_supportbar_v005.svg
59 kB
Materials
1/4" diameter, 3/4" long, delrin dowels: https://www.mcmaster.com/97155A639
Veritas bench blade: https://www.leevalley.com/en-ca/shop/tools/workshop/workbenches/benchtop-accessories/64685-veritas-bench-blade
Veritas low profile work stop: https://www.leevalley.com/en-ca/shop/hardware/jig-and-fixture-parts/73499-veritas-low-profile-work-stop
3/4" x 1/2" t track
You may need thinner 1/4" 20 oval nuts, the ones that ship with the clamp are a little thick to fit some t track profiles.
Tools
Origin
1/4" stock cutter
Instructions
Cut interior details first. 1/4" indexing holes are cut to 1/2" deep sholders for 2 mounting holes are 1/2" deep Measure your T track ( the sizes can vary ) this is Cut the slot for 3/4" wide by 1/2" deep T track. Test fit your T track to confirm you are at the right depth, it is best to be ever so slightly sub flush. Drill and countersink holes in the t track for mounting ( be sure to avoid the aluminium support if the screws extend beyond the base. Screw in the t track and cut to length.
