Linnea EP 100

By Sam | Created July 3rd, 2019 | Published July 3rd, 2019

uploaded project image
project image thumbnail
project image thumbnail
project image thumbnail
project image thumbnail
Install a linnea folding door pull

10 min

Easy

6

Category

Hardware Inserts

Files included (1)
NameSize
EP_100_v002.svg
8 kB

Linnea EP-100
Origin 1/4" stock cutter
Cut the shallow pass first, take care as this is the visible cut when the hardware is installed. cut the deeper pass to the defined depth. Test fit the hardware, it should press into place. adjust offsets to tune the friction fit.

This project is licensed under the Creative Commons Attribution - NonCommerical - Share - Alike license
